Product Description

Submersible Pump Cast Iron 8 inch INNDP830a

Technical Specifications

Frequency: 50 Hz

Outlet connection diameter: 4-5" (inside gear)

Max. sand content: 50 gr / m

Pump outside diameter: 185 mm

Number of the vane: 6

Degree of protection: IP 68

Voltage: 380-415 V (+%6 / -%10)

Direction Of Rotation: Counter-clockwise

Max. water temperature: 35º C (50º C opsiyonel)

Diffuser: Cast Iron (GG22-GG25)

Impeller: Cast Iron (GG22-GG25)

Pump shaft: Stainless steel (AISI 420)

Coupling: Stainless steel (AISI 420)

Strainer: Stainless steel (AISI 304)

Valve cap: Cast Iron (GG22-GG25)

Connection: Based on NEMA standarts

Area of Use

Water supply

Drinking-water wells

Agrycultural irrigation

Geotermal wells

Sea water transfer

Specifications

Cast iron pumps are economic and efficient

Cast iron submersible pumps are designed to operate with clean water.

The body and fan materials are available as standard GG22 material

By request it can be made from special materials
