Stainless Steel Submersible Pump 6-inch 46m³/h INNSP646 Capacity (Max): 57 m³/hour, 15.7 liters/second, 253 GPM Most efficient operating point of the pump: 46m³ Immersion depth (Max): 488 meters Frequency: 50 Hz Outlet connection: 4" (female thread) Max. sand content: 50 g/m³ Pump outer diameter: 144 mm Number of impeller vanes: 6 Protection class: IP 68 Maximum voltage variation: 380–415 V (+6% / -10%) Direction of rotation: Counter-clockwise Maximum water temperature: 30°C (50°C optional) Diffuser: Stainless steel (AISI 304L) Impeller: Stainless steel (AISI 304L) Pump shaft: Stainless steel (AISI 420) Coupling: Stainless steel (AISI 420) Strainer: Stainless steel (AISI 304) Check valve: Stainless steel Motor connection: Compliant with NEMA standards
Submersbile Pump Stainless Steel 6 inch 46 m3 INNSP646 Frequency： 50 Hz Outlet connection diameter: 4" (inside gear) Max. sand quantity: 50 ar / m Pump outside diameter: 144 mm Number of the vane: 6 Degree of protection: IP 68 Voltage: 380-415 V (+ %6 / -%10' Rotation: Counter-clockwise Max. water temperature: 30° C (50° C optional) Case: Stainless steel (AISI 304L) Diffuser: Stainless steel (AISI 304L) Impeller: Stainless steel (AISI 420) Pump shaft: Stainless steel (AISI 420)
A passport has not yet been published for this product.
6 Inch Stainless Steel Submersible Pump 45 m³/h INNSP646 | Heavy Duty Deep Well Pump
